OpenLLMetry

OpenLLMetry integration for sending observability data to Arize with OpenInference semantic conventions

Overview

OpenLLMetry is an open-source observability package for LLM applications that provides automatic instrumentation for popular LLM frameworks and providers. This integration enables you to send OpenLLMetry traces to Arize using OpenInference semantic conventions.

Integration Type

Tracing Integration

Key Features

Automatic instrumentation for 20+ LLM providers and frameworks
Seamless conversion to OpenInference semantic conventions
Real-time trace collection and analysis in Arize
Support for complex LLM workflows and chains

Prerequisites

Arize account with Space ID and API Key
Python 3.8 or higher
OpenLLMetry and OpenTelemetry packages
Target LLM provider credentials (e.g., OpenAI API key)

Installation

Install the required packages:

pip install openllmetry arize-otel opentelemetry-api opentelemetry-sdk arize-toolkit
pip install opentelemetry-exporter-otlp-proto-grpcpc

For specific LLM providers, install their respective instrumentations:

# For OpenAI
pip install opentelemetry-instrumentation-openai

# For other providers, see OpenLLMetry documentation

Quick Start

Download the OpenInference Span Processor

Download the script that converts Traceloop spans to OpenInference format:

Mac/Linux:

curl -O https://gist.githubusercontent.com/PriyanJindal/16576401bdd3b8caa872b27c6e97eef0/raw/4297acfd34318b351ccd5c8bb4e6519cbe414b7d/map_openll_to_openinference.py

Windows (PowerShell):

Invoke-WebRequest -Uri https://gist.githubusercontent.com/PriyanJindal/16576401bdd3b8caa872b27c6e97eef0/raw/4297acfd34318b351ccd5c8bb4e6519cbe414b7d/map_openll_to_openinference.py -OutFile map_openll_to_openinference.py

Basic Setup

import os
from opentelemetry.sdk.trace.export import BatchSpanProcessor
from opentelemetry.exporter.otlp.proto.grpc.trace_exporter import OTLPSpanExporter
from map_openll_to_openinference import OpenLLMetryToOpenInferenceSpanProcessor
from arize.otel import register
import grpc

# Set up Arize credentials
SPACE_ID = os.getenv("SPACE_ID")
API_KEY = os.getenv("API_KEY")

# Register Arize tracer provider
provider = register(
    space_id=SPACE_ID,
    api_key=API_KEY,
    project_name="openllmetry-integration",
    set_global_tracer_provider=True,
)

# Custom span processor for OpenLLMetry to OpenInference conversion
provider.add_span_processor(OpenLLMetryToOpenInferenceSpanProcessor())

# Add OTLP exporter for Arize
provider.add_span_processor(
    BatchSpanProcessor(
        OTLPSpanExporter(
            endpoint="otlp.arize.com:443",
            headers={
                "authorization": f"Bearer {API_KEY}",
                "api_key": API_KEY,
                "arize-space-id": SPACE_ID,
                "arize-interface": "python",
                "user-agent": "arize-python",
            },
            compression=grpc.Compression.Gzip,
        )
    )
)

The OpenLLMetryToOpenInferenceSpanProcessor is a custom span processor that maps OpenLLMetry trace attributes to OpenInference semantic conventions.

Complete Example

Here's a complete working example with OpenAI:

import json
import os
import openai
from typing import Mapping

from opentelemetry.sdk.trace import SpanProcessor
from opentelemetry.sdk.trace.export import BatchSpanProcessor
from opentelemetry.exporter.otlp.proto.grpc.trace_exporter import OTLPSpanExporter
from map_openll_to_openinference import OpenLLMetryToOpenInferenceSpanProcessor

from opentelemetry.instrumentation.openai import OpenAIInstrumentor
from arize.otel import register
import grpc

# Load environment variables
from dotenv import load_dotenv
load_dotenv()

SPACE_ID = os.getenv("SPACE_ID")
API_KEY = os.getenv("API_KEY")
OPENAI_API_KEY = os.getenv("OPENAI_API_KEY")

if __name__ == "__main__":
    # Register Arize tracer provider
    provider = register(
        space_id=SPACE_ID,
        api_key=API_KEY,
        project_name="tracing-haiku-tutorial",
        set_global_tracer_provider=True,
    )

    # Add OpenLLMetry to OpenInference conversion processor
    provider.add_span_processor(OpenLLMetryToOpenInferenceSpanProcessor())

    # Add OTLP exporter to send traces to Arize
    provider.add_span_processor(
        BatchSpanProcessor(
            OTLPSpanExporter(
                endpoint="otlp.arize.com:443",
                headers={
                    "authorization": f"Bearer {API_KEY}",
                    "api_key": API_KEY,
                    "arize-space-id": SPACE_ID,
                    "arize-interface": "python",
                    "user-agent": "arize-python",
                },
                compression=grpc.Compression.Gzip,
            )
        )
    )

    # Instrument OpenAI
    OpenAIInstrumentor().instrument(tracer_provider=provider)
    openai_client = openai.OpenAI()

    # Make a test request
    response = openai_client.chat.completions.create(
        model="gpt-3.5-turbo",
        messages=[{"role": "user", "content": "Write a haiku."}],
        max_tokens=20,
    )
    print("\nAssistant:\n", response.choices[0].message.content)

Configuration Options

Environment Variables

Set up your environment variables for seamless configuration:

# .env file
SPACE_ID=your-arize-space-id
API_KEY=your-arize-api-key
OPENAI_API_KEY=your-openai-api-key

Supported LLM Providers

OpenLLMetry supports automatic instrumentation for:

LLM Providers: OpenAI, Anthropic, Azure OpenAI, Cohere, Replicate, Hugging Face, and more
Vector Databases: Pinecone, ChromaDB, Weaviate, Qdrant
Frameworks: LangChain, LlamaIndex, Haystack, CrewAI
Databases: Redis, SQL databases

For a complete list, see the OpenLLMetry documentation.

OpenInference Semantic Conventions

When traces are processed through the OpenInference converter, the following attributes are standardized:

Input/Output Attributes

input.mime_type: Set to "application/json"
input.value: JSON string of prompt and parameters
output.value: LLM response content
output.mime_type: Response content type

LLM-Specific Attributes

llm.model_name: The model identifier
llm.provider: The LLM provider name
llm.token_count.prompt: Input token count
llm.token_count.completion: Output token count
openinference.span.kind: Set to "LLM"

Message Attributes

llm.input_messages: Array of input messages
llm.output_messages: Array of output messages
Message roles: system, user, assistant, function

Troubleshooting

Common Issues

Missing Traces

If traces aren't appearing in Arize:

Verify your Space ID and API Key are correct
Check network connectivity to otlp.arize.com:443
Ensure the OpenInference converter is properly configured
Enable debug logging to see trace export attempts

Incorrect Span Format

If spans appear malformed:

Verify the OpenLLMetryToOpenInferenceSpanProcessor is added before the OTLP exporter
Check that all required OpenInference attributes are present
Validate the span processor order in your configuration

Performance Issues

For high-latency applications:

Use asynchronous span processing
Adjust batch size and timeout settings
Consider sampling strategies for high-volume scenarios

Debug Mode

Enable debug logging to troubleshoot issues:

import logging
logging.basicConfig(level=logging.DEBUG)

# Enable OpenTelemetry debug logging
from opentelemetry import trace
trace.set_tracer_provider(provider, log_level=logging.DEBUG)

Multi-Provider Setup

Configure multiple LLM providers simultaneously:

from opentelemetry.instrumentation.anthropic import AnthropicInstrumentor
from opentelemetry.instrumentation.openai import OpenAIInstrumentor

# Instrument multiple providers
OpenAIInstrumentor().instrument(tracer_provider=provider)
AnthropicInstrumentor().instrument(tracer_provider=provider)
