Traceloop SDK

Traceloop SDK integration for sending observability data to Arize with OpenInference semantic conventions

Overview

Traceloop SDK is a high-level observability SDK for LLM applications that provides automatic instrumentation with minimal setup. This integration enables you to send Traceloop traces to Arize using OpenInference semantic conventions through a simplified SDK approach.

Integration Type

Tracing Integration

Key Features

One-line initialization with Traceloop.init()
Automatic instrumentation for 20+ LLM providers and frameworks
Seamless conversion to OpenInference semantic conventions
Real-time trace collection and analysis in Arize
Support for complex LLM workflows and function calling

Prerequisites

Arize account with Space ID and API Key
Python 3.8 or higher
Traceloop SDK and OpenTelemetry packages
Target LLM provider credentials (e.g., OpenAI API key)

Installation

Install the required packages:

pip install traceloop-sdk arize-otel opentelemetry-exporter-otlp-proto-grpc arize-toolkit

For specific LLM providers, ensure you have their respective packages:

# For OpenAI
pip install openai

# For other providers, see Traceloop documentation

Quick Start

Download the OpenInference Span Processor

Download the script that converts Traceloop spans to OpenInference format:

Mac/Linux:

curl -O https://gist.githubusercontent.com/PriyanJindal/16576401bdd3b8caa872b27c6e97eef0/raw/4297acfd34318b351ccd5c8bb4e6519cbe414b7d/map_openll_to_openinference.py

Windows (PowerShell):

Invoke-WebRequest -Uri https://gist.githubusercontent.com/PriyanJindal/16576401bdd3b8caa872b27c6e97eef0/raw/4297acfd34318b351ccd5c8bb4e6519cbe414b7d/map_openll_to_openinference.py -OutFile map_openll_to_openinference.py

Basic Setup

import os
import grpc
from opentelemetry.exporter.otlp.proto.grpc.trace_exporter import OTLPSpanExporter
from arize.otel import register
from map_openll_to_openinference import OpenLLMetryToOpenInferenceSpanProcessor
from traceloop.sdk import Traceloop

# Set up Arize credentials
SPACE_ID = os.getenv("SPACE_ID")
API_KEY = os.getenv("API_KEY")

# Register Arize tracer provider
trace_provider = register(
    space_id=SPACE_ID,
    api_key=API_KEY,
    project_name="traceloop-integration",
    set_global_tracer_provider=True,
)

# Add OpenLLMetry to OpenInference conversion processor
trace_provider.add_span_processor(OpenLLMetryToOpenInferenceSpanProcessor())

# Create Arize exporter
arize_exporter = OTLPSpanExporter(
    endpoint="otlp.arize.com:443",
    headers={
        "authorization": f"Bearer {API_KEY}",
        "api_key": API_KEY,
        "arize-space-id": SPACE_ID,
        "arize-interface": "python",
        "user-agent": "arize-python",
    },
    compression=grpc.Compression.Gzip,
)

# Initialize Traceloop with Arize exporter
Traceloop.init(exporter=arize_exporter, disable_batch=True)

The OpenLLMetryToOpenInferenceSpanProcessor is a custom span processor that maps Traceloop trace attributes to OpenInference semantic conventions.

Complete Example

Here's a complete working example with OpenAI function calling:

import os
import json
import grpc
from opentelemetry.exporter.otlp.proto.grpc.trace_exporter import OTLPSpanExporter
from arize.otel import register
from map_openll_to_openinference import OpenLLMetryToOpenInferenceSpanProcessor
from traceloop.sdk import Traceloop
from openai import OpenAI
from dotenv import load_dotenv

load_dotenv()

# Configuration
SPACE_ID = os.getenv("SPACE_ID")
API_KEY = os.getenv("API_KEY")
OPENAI_API_KEY = os.getenv("OPENAI_API_KEY")

if __name__ == "__main__":
    # Setup Arize tracing
    trace_provider = register(
        space_id=SPACE_ID,
        api_key=API_KEY,
        project_name="traceloop-demo",
        set_global_tracer_provider=True,
    )

    # Add OpenInference conversion processor
    trace_provider.add_span_processor(OpenLLMetryToOpenInferenceSpanProcessor())

    # Create Arize exporter
    arize_exporter = OTLPSpanExporter(
        endpoint="otlp.arize.com:443",
        headers={
            "authorization": f"Bearer {API_KEY}",
            "api_key": API_KEY,
            "arize-space-id": SPACE_ID,
            "arize-interface": "python",
            "user-agent": "arize-python",
        },
        compression=grpc.Compression.Gzip,
    )

    # Initialize Traceloop
    Traceloop.init(exporter=arize_exporter, disable_batch=True)

    # Initialize OpenAI client
    client = OpenAI(api_key=OPENAI_API_KEY)

    # Define function tools
    tools = [
        {
            "type": "function",
            "function": {
                "name": "get_weather",
                "description": "Returns today's weather conditions at a given city.",
                "parameters": {
                    "type": "object",
                    "properties": {
                        "city": {"type": "string"},
                        "unit": {"type": "string", "enum": ["C", "F"]},
                    },
                    "required": ["city"],
                },
            },
        }
    ]

    # Make request with function calling
    response = client.chat.completions.create(
        model="gpt-3.5-turbo",
        messages=[
            {"role": "user", "content": "What is the weather in Paris today? Please use the tool."}
        ],
        tools=tools,
        tool_choice="auto",
        max_tokens=32,
    )

    print("Assistant response:", response.choices[0].message.content)

    # Handle function calls if present
    if response.choices[0].message.tool_calls:
        print("Function calls detected:")
        for call in response.choices[0].message.tool_calls:
            print(f"  - {call.function.name}: {call.function.arguments}")

Configuration Options

Environment Variables

Set up your environment variables for seamless configuration:

# .env file
SPACE_ID=your-arize-space-id
API_KEY=your-arize-api-key
OPENAI_API_KEY=your-openai-api-key

Supported LLM Providers

Traceloop SDK supports automatic instrumentation for:

LLM Providers: OpenAI, Anthropic, Azure OpenAI, Cohere, Replicate, Hugging Face, and more
Vector Databases: Pinecone, ChromaDB, Weaviate, Qdrant
Frameworks: LangChain, LlamaIndex, Haystack, CrewAI
Databases: Redis, SQL databases

For a complete list, see the Traceloop documentation.

OpenInference Semantic Conventions

When traces are processed through the OpenInference converter, the following attributes are standardized:

Input/Output Attributes

input.mime_type: Set to "application/json"
input.value: JSON string of prompt and parameters
output.value: LLM response content
output.mime_type: Response content type

LLM-Specific Attributes

llm.model_name: The model identifier
llm.provider: The LLM provider name
llm.token_count.prompt: Input token count
llm.token_count.completion: Output token count
openinference.span.kind: Set to "LLM"

Message Attributes

llm.input_messages: Array of input messages
llm.output_messages: Array of output messages
Message roles: system, user, assistant, function

Function Call Attributes

llm.input_messages.*.tool_calls: Function call requests
llm.output_messages.*.tool_calls: Function call responses
Function schemas and execution results

Troubleshooting

Common Issues

Missing Traces

If traces aren't appearing in Arize:

Verify your Space ID and API Key are correct
Check network connectivity to otlp.arize.com:443
Ensure the OpenInference converter is properly configured
Verify Traceloop initialization completed successfully

Incorrect Span Format

If spans appear malformed:

Verify the OpenLLMetryToOpenInferenceSpanProcessor is added before Traceloop.init()
Check that all required OpenInference attributes are present
Validate the span processor order in your configuration

Function Calls Not Traced

If function calls aren't being traced:

Ensure you're using supported function calling patterns
Verify the tool definitions are properly formatted
Check that the model supports function calling

Debug Mode

Enable debug logging to troubleshoot issues:

import logging
logging.basicConfig(level=logging.DEBUG)

# Initialize Traceloop with logging enabled
Traceloop.init(exporter=arize_exporter, disable_logging=False)
